Solar Power Plant Monitoring Solutions:
Solar Power Plant users need a complete and comprehensive monitoring system, which is accessible from a local plant as well as remote stations and have access to power generation and export data in real-time.
SCES offers a well-designed Data Acquisition System and Control to assist Power Generation and have proven capabilities to Design, Manufacture, install, integrate and commission Solar Power Plant Monitoring Systems of more than 600 MW.
The SCADA system used for Data Monitoring is very user-friendly and fully-scalable to meet future requirements if any. An user can navigate through various screens on a HMI & Monitor real-time data of Power Generation, Power export, system voltage, current, atmospheric conditions, alarms from a Central Control Room Monitoring system.
At the same time, data from power meters, relays, transformers, inverters, AJBs/SMBs, strings is obtained for better operation and maintenance of the installation. Users can also generate customized reports and analyse historical data.
Parameters to be Monitored, Displayed & Stored
- String Monitoring Boxes: Total Voltage , PCB Current , Fuse status of individual string , Minimum current alarm and Zero current alarm etc.
- Inverters: Active & Reactive Power, Apparent power, Grid Voltage & Current, PV Voltage , Current & Power, Energy generation, Total Energy generation, Power factor, Temperature, Any Error & Failure etc.
- RMUs and Transformer: RMU status , Winding Temperature, Oil Temperature and Buchholz Relay status etc.
- Multi-function Meter: Active & Reactive Power, Apparent Power, Average Current, VLL & VLN, Frequency, System on demand, System max demand etc.
- Protective Relay: Active & Reactive Power, Current , Voltage and Frequency etc.
- Weather Station: Solar radiation, Temperature IN & OUT, Humidity IN & OUT, Wind speed & Wind direction, Barometer pressure & Day rainfall etc.
